Outdoor LED Screen Malaysia
We offer a range of Outdoor LED Screen & Display in Malaysia to meet diverse needs, providing detailed information on performance, dimensions, and capabilities. Our high-quality Outdoor LED Display solutions are designed to help you choose the best option for your specific application in Malaysia.
Models & Specifications
We offer a range of Outdoor LED Screen & Display in Malaysia to meet diverse needs, providing detailed information on performance, dimensions, and capabilities. Our high-quality Outdoor LED Display solutions are designed to help you choose the best option for your specific application in Malaysia.
P4
Module Size256 x 128
| Pixel Pitch (mm) | 4mm |
|---|---|
| Pixel Density | 62500pixel/m2 |
| Pixel Configuration | 1R1G1B |
| LED Lamp | SMD3528 |
| White Brightness | >1600cd |
| Refresh Rate | >1000Hz/s |
| Grey Scale | >16.7M color |
| Module Resolution | 64 x 32 |
| Cabinet Size | 768 x 768 |
| Cabinet Weight | 26kg |
| Viewing Distance | 12-120m |
| Drive Mood | 1/16 scan |
| Operation Temperature | 20 C – 50 C |
| Max Power Consumption | 650W |
| Control System | Linsn / Nova |
| IP Level | IP 65 |
| Life Span | >100,000 hours |
P5
| Pixel Pitch (mm) | 5mm |
|---|---|
| Pixel Density | 40000pixel/m2 |
| Pixel Configuration | 1R1G1B |
| LED Lamp | SMD3535 |
| White Brightness | >7000cd |
| Refresh Rate | >1000Hz/s |
| Grey Scale | >16.7M color |
| Module Resolution | 32 x 32 |
| Module Size | 160 x 160 |
| Cabinet Size | 960 x 960 |
| Cabinet Weight | 60kg |
| Viewing Distance | 5-150m |
| Drive Mood | 1/8 scan |
| Operation Temperature | 20 C – 50 C |
| Max Power Consumption | 1200W |
| Control System | Linsn / Nova |
| IP Level | IP 65 |
| Life Span | >100,000 hours |
P6
| Pixel Pitch (mm) | 6mm |
|---|---|
| Pixel Density | 27777pixel/m2 |
| Pixel Configuration | 1R1G1B |
| LED Lamp | SMD3535 |
| White Brightness | >7000cd |
| Refresh Rate | >1000Hz/s |
| Grey Scale | >16.7M color |
| Module Resolution | 32 x 16 |
| Module Size | 192 x 192 |
| Cabinet Size | 960 x 960 |
| Cabinet Weight | 60kg |
| Viewing Distance | 6-160m |
| Drive Mood | 1/4 scan |
| Operation Temperature | 20 C – 50 C |
| Max Power Consumption | 1700W |
| Control System | Linsn / Nova |
| IP Level | IP 65 |
| Life Span | >100,000 hours |
P8
| Pixel Pitch (mm) | 8mm |
|---|---|
| Pixel Density | 15625pixel/m2 |
| Pixel Configuration | 1R1G1B |
| LED Lamp | SMD3535 / DIP246 |
| White Brightness | >5500cd |
| Refresh Rate | >1000Hz/s |
| Grey Scale | >16.7M color |
| Module Resolution | 32 x 16 |
| Module Size | 256 x 128 |
| Cabinet Size | 1024 x 1024 |
| Cabinet Weight | 65kg |
| Viewing Distance | 8-180m |
| Drive Mood | 1/4 scan |
| Operation Temperature | 20 C – 50 C |
| Max Power Consumption | 980W |
| Control System | Linsn / Nova |
| IP Level | IP 65 |
| Life Span | >100,000 hours |
P10
| Pixel Pitch (mm) | 10mm |
|---|---|
| Pixel Density | 10000pixel/m2 |
| Pixel Configuration | 1R1G1B |
| LED Lamp | SMD3535 / DIP346 |
| White Brightness | >7000cd |
| Refresh Rate | >1000Hz/s |
| Grey Scale | >16.7M color |
| Module Resolution | 16 x 16 |
| Module Size | 320 x 160 |
| Cabinet Size | 960 x 960 |
| Cabinet Weight | 60kg |
| Viewing Distance | 10-100m |
| Drive Mood | 1/4 scan |
| Operation Temperature | 20 C – 50 C |
| Max Power Consumption | 1000W |
| Control System | Linsn / Nova |
| IP Level | IP 65 |
| Life Span | >100,000 hours |
P12
| Pixel Pitch (mm) | 12mm |
|---|---|
| Pixel Density | 6944pixel/m2 |
| Pixel Configuration | 1R1G1B |
| LED Lamp | SMD3535 / DIP346 |
| White Brightness | >5500cd |
| Refresh Rate | >1000Hz/s |
| Grey Scale | >16.7M color |
| Module Resolution | 16 x 16 |
| Module Size | 192 x 192 |
| Cabinet Size | 960 x 960 |
| Cabinet Weight | 60kg |
| Viewing Distance | 12-120m |
| Drive Mood | 1/4 scan |
| Operation Temperature | 20 C – 50 C |
| Max Power Consumption | 700W |
| Control System | Linsn / Nova |
| IP Level | IP 65 |
| Life Span | >100,000 hours |
P16
| Pixel Pitch (mm) | 16mm |
|---|---|
| Pixel Density | 3906pixel/m2 |
| Pixel Configuration | 1R1G1B |
| LED Lamp | DIP346 |
| White Brightness | >7500cd |
| Refresh Rate | >1000Hz/s |
| Grey Scale | >16.7M color |
| Module Resolution | 16 x 16 |
| Module Size | 256 x 256 |
| Cabinet Size | 1024 x 1024 |
| Cabinet Weight | 65kg |
| Viewing Distance | 16-160m |
| Drive Mood | Static |
| Operation Temperature | 20 C – 50 C |
| Max Power Consumption | 980W |
| Control System | Linsn / Nova |
| IP Level | IP 65 |
| Life Span | >100,000 hours |
P20
| Pixel Pitch (mm) | 20mm |
|---|---|
| Pixel Density | 2500pixel/m2 |
| Pixel Configuration | 2R1G1B |
| LED Lamp | DIP346 |
| White Brightness | >6000cd |
| Refresh Rate | >1000Hz/s |
| Grey Scale | >16.7M color |
| Module Resolution | 16 x 8 |
| Module Size | 320 x 160 |
| Cabinet Size | 1280 x 1280 |
| Cabinet Weight | 70kg |
| Viewing Distance | 20-200m |
| Drive Mood | Static |
| Operation Temperature | 20 C – 50 C |
| Max Power Consumption | 650W |
| Control System | Linsn / Nova |
| IP Level | IP 65 |
| Life Span | >100,000 hours |
P25
| Pixel Pitch (mm) | 25mm |
|---|---|
| Pixel Density | 1600pixel/m2 |
| Pixel Configuration | 2R1G1B |
| LED Lamp | DIP346 |
| White Brightness | >4500cd |
| Refresh Rate | >1000Hz/s |
| Grey Scale | >16.7M color |
| Module Resolution | 16 x 8 |
| Module Size | 200 x 200 |
| Cabinet Size | 1200 x 1200 |
| Cabinet Weight | 70kg |
| Viewing Distance | 25-250m |
| Drive Mood | Static |
| Operation Temperature | 20 C – 50 C |
| Max Power Consumption | 650W |
| Control System | Linsn / Nova |
| IP Level | IP 65 |
| Life Span | >100,000 hours |
Magnetic Frame, Quick Installation
It has a dedicated black frame and fast lock design, freehand installation, no tools, and a double install speed for the die-casting cabinet. The flatness level is up to the first level. It can be a suked screen, hand printing, handing hongs, handing flower walls, handing lights, or a lamp screen combination. It is multi-purpose and has multiple programs that adapt to various occasions.
Outdoor Digital Signage Solutions
Indoor environments like meeting rooms, conferences, exhibitions, and retail spaces.
Outdoor environments like digital signage, advertising boards, and public spaces.
Medium to long-range viewing for both indoor and outdoor use due to the versatile pixel pitch.
⦿ Advertising & Promotion
⦿ Events & Entertainment
⦿ Sports & Stadiums
⦿ Public & Transportation Displays
Outdoor LED Display Applications in Malaysia
Our Outdoor LED Displays withstand all weather conditions and deliver bright,
high-resolution visuals, enhancing advertising, live events, and public information.
Why Choose
Our Outdoor LED Screen?
With precise control module installation and advanced wave soldering technology, our Outdoor LED Screens
resist moisture and oxidation, ensuring long-lasting environmental performance.
Wide Viewing Angle
Offers a wide viewing angle and smooth display, ensuring excellent image quality and visibility from all perspectives.
Ultra-High Brightness & Durability
Features ultra-high brightness with low attenuation, offering reliable performance and durability in various weather conditions.
IP65 Rating
Guarantees that our LED screens remain stable and fully operational even in severe weather conditions.
Colour Uniformity
Provides excellent colour uniformity, ensuring a smooth, clear display without any coarseness or mosaic effects.
Frequently Asked Question (FAQs)
What is the optimal viewing distance for an LED wall?
The ideal viewing distance is generally 2-3 times the pixel pitch in meters. For instance, a narrow pixel pitch of 2 allows viewing from 4 meters away, while a pixel pitch of 10 requires at least 20 meters for optimal detail.
What is the pixel pitch of the LED Screen?
Pixel pitch is the center-to-center distance between adjacent pixels, measured in millimeters. Simply put, it indicates the gap between the pixels of the LED display. A smaller pixel pitch indicates less space between pixels and a higher pixel count, which leads to improved resolution and higher image quality. The figure below shows the pixel pitch for a high-resolution SMD LED module and a high-resolution DIP LED module.
What is the effect of pixel pitch size on image quality?
For most LED wall applications, 1080p resolution can be achieved using standard pixel pitch and viewing distance guidelines. A lower pixel pitch is recommended for higher resolution. However, the image quality and content you render on the LED wall are important considerations.
