Transparent LED Screen
A transparent LED screen is a display built from thin LED strips spaced far enough apart that you can see straight through the gaps. Mounted against a shop window or a glass curtain wall, it turns the glass into a moving display while the daylight still comes through and people can still see in and out. Solid LED screens block the window completely, which is why retailers who try them usually end up with a boarded-up shopfront and a darker interior.
How Much Can We See Through?
Transparency is measured as a percentage of light passing through. Our transparent LED display offers up to 60% to 90% transparency, depending on the selected model and pixel pitch. The trade-off is straightforward: higher transparency means a more open view and a lower brightness ceiling, while lower transparency means a denser, brighter image and more obstruction. Which one is right depends on whether the window matters more than the picture, and that is usually a decision the tenant and the landlord need to make together.
How It Installs Onto Existing Glass
The question we are asked most often is whether the glass has to come out. It does not. The screen mounts to the inside face of your existing glazing, typically hung from a track at the head of the opening or fixed to the existing mullions, so the facade itself is untouched.
High Refresh,
High Grayscale
High refresh and grayscale, refresh rate ≥ 3840
Product Features
Our product features are designed to provide exceptional performance, reliability, and ease of use, ensuring our solutions meet the highest standards for various applications.
Fast Installation and Maintenance
The integrated design combines the module, power supply and receiving card into a single unit, so installation is a matter of mounting and connecting rather than assembling on site. Maintenance is done from the front through a plug-type back cover, which means a faulty unit can be swapped without dismantling the screen or accessing it from behind. On a shopfront installation with a wall directly behind the glass, that is often the difference between a serviceable screen and one that cannot be repaired in place.
High Transparency and Wind Resistance
The open structure that lets light through also lets air through, which is what allows these screens to be installed on exposed facades and in atria without the wind loading that a solid screen would generate.
Hanging Bar
The hanging bar system supports the screen from above rather than requiring a floor-mounted frame, so the installation stays clear of the floor and the shopfront remains usable. It also makes the screen straightforward to remove and relocate, which suits short-lease retail units.
Quick Installation Lock
Cabinets connect with a quick-lock mechanism rather than bolted fixings, so panels align accurately and the installation goes up faster. Faster installation matters more on this product than on most, because shopfront and facade work usually has to happen outside trading hours.
Models & Specifications
We offer a range of options to meet diverse needs, providing detailed information on performance, dimensions,
and capabilities to help you choose the best solution for your application.
P3.91-7.81 – Transparent Series
| Pixel Pitch | P3.91-7.81mm |
|---|---|
| SMD | SMD2121 |
| Cabinet Size | 500 x 1000 |
| Screen Brightness | >3000cd |
| Best Viewing Distance | 4-40 meter |
| Life Span | 100,000 hours |
| Viewing Angle | 140 / 140 |
| Refresh Rate | >3840 Hz |
| IP Rating | IP 65 |
| Ambient Temperature and Humidity | -20 C ~+ 50 C, RH=40~90% |
P6.944 – Transparent Series
| Pixel Pitch | P6.944mm |
|---|---|
| SMD | SMD1921 |
| Cabinet Size | 500 x 100 |
| Screen Brightness | >3000cd |
| Best Viewing Distance | 7-100 meter |
| Life Span | 100,000 hours |
| Viewing Angle | 140 / 140 |
| Refresh Rate | >3840 Hz |
| IP Rating | IP 65 |
| Ambient Temperature and Humidity | -20 C ~+ 50 C, RH=40~90% |
Why Choose
Our Transparent LED Screen?
Our Transparent LED Screens offer eye-catching visuals and sleek design, perfect for retail and architecture.
They provide high visibility and vibrant displays that enhance your space.
Lightweight
Light and thin, each single cabinet weighs only 6kg, making it easy to handle and install without compromising strength and stability.
Easy Maintenance
With an integrated pinboard and power supply, the plug-type design on the back cover ensures easy maintenance.
Built for the Malaysian Climate
Rated for -20°C to +50°C, 40–90% humidity, and IP65 protection, ensuring reliable performance in Malaysia’s hot and humid climate.
Installed, Warranted and Supported Nationwide
We handle survey, supply, installation and maintenance across Malaysia, with a two-year warranty, 24-hour response support and a free site consultation.
Ventilation Design
Our product’s advanced ventilation design ensures quick heat dissipation and strong wind resistance for enhanced durability and performance.
High Refresh Rate & Grayscale
Our product delivers smooth, detailed, and accurate visuals for an enhanced viewing experience.
Transparent LED Screen Display
Applications
Our Transparent LED Screens offer high-resolution visuals without blocking views.
Ideal for interactive content and seamless integration.
